The DL3M series has very small dimensions and the model with 15 degree lens allows the design of spot lighting systems. The light beam is concentrated in very precise areas and with a strong intensity.
Tag: artificial vision
Multispot and multi-angle configurations with chain connection
The ability of DL3M LED series to manage multiple illuminators connected in a chain configuration also allows the design of systems that require multi-angle lighting or systems where the light diffusion must be created with a large number of single spots.
Read More “Multispot and multi-angle configurations with chain connection”
Multispot configurations with chain connection
The particularity of the DL3M family of LED illuminators is the possibility of creating distributed lighting systems. Each single illuminator can be connected in series with a “chain” configuration capable of powering up to 6 illuminators with the same power supply. The power supply can be connected to a traditional 24Vdc power line. The driver can be fixed to a DIN rail and can manage a remote ON/OFF signal to control the illuminator by PLC, PC or external electronic controllers.
Miniature LED illuminators for backlight applications on very small objects
The new DL3M Series LED illuminators also allow the creation of smaller backlighting systems. The use of an opal glass installed in place of the transparent glass makes it possible to create a uniformly illuminated surface for the creation of vision systems that work with the principle of shadow projection.
Read More “Miniature LED illuminators for backlight applications on very small objects”
Miniature LED lighters for ROBOT guide on conveyor belts
The new DL3M series can be used for the design of distributed lighting on conveyor belts or on robot work areas where it is necessary to search for unordered products.
The possibility of creating chains of several illuminators connected to a single power supply allows the distribution of light even in very large work areas.
Each individual illuminator can be configured with a different wavelength or with a different light diffusion mode (3 different types of lenses and 2 different types of diffuser glasses). It is therefore possible to create systems with multi-color lighting or systems with different levels of light diffusion.
Read More “Miniature LED lighters for ROBOT guide on conveyor belts”
Use of optical filters in machine vision systems
Optical filters are critical components for machine vision applications. They’re used to maximize contrast, improve color, enhance subject recognition and control the light that’s reflected from the object being inspected. A machine vision filter is not just a machine vision filter. Here’s what to look for when choosing a filter for your machine vision system:
Complete line of filters, single substrate and with high hardness coating, specially created for industrial machine vision applications.
Filters for vision systems increase the contrast of the object under control, improving the system’s ability to distinguish the desired characteristics.
A higher contrast allows a higher inspection precision and higher speed of the inspection system. The effect of the presence of ambient light, or of its possible variation over time, is minimized with the use of filters, thus creating the conditions for a good stability of the operating conditions of the vision system in the long run.
Read More “Use of optical filters in machine vision systems”
Miniature LED illuminators for vision systems
The new miniature LED illuminators DC3M series by RODER SRL allow the design of compact vision systems based on industrial cameras. DC3M series illuminators are designed for the construction of industrial division systems and optical test benches where compactness and high beam brightness are required.
Miniature LED illuminators DC3M are designed for lighting applications in direct lighting mode, with high uniformity and absence of shaded areas.
Backlight LED illumination for vision systems based on shadow projection
RODER Vision presents the new family of miniature LED lighter for backlight illumination in vision systems.
The new BL3 family is the latest family of LED lighter for vision systems and optical test benches.
Read More “Backlight LED illumination for vision systems based on shadow projection”
Bar LED illuminators for robot guide on belt conveyor systems
RODER Vision presents the new family of bar LED illuminators for direct illumination in vision systems on belt conveyor systems
The new DL2 family is the latest family of LED lighter for vision systems and optical test benches.
Read More “Bar LED illuminators for robot guide on belt conveyor systems”
LED illuminators for linear camera systems
RODER Vision presents the new family of LED illuminators for direct illumination in vision systems based on linear camera.
The new DL1 family is the latest family of LED lighter for vision systems and optical test benches.
